* DMX 512/1990 Standard
* 48 DMX channels with optical isolated output
* 24 channel faders×2 pages, 24 Flash buttons×2 pages
* 6 Submaster faders, 6 Submaster buttons
* 1 Master faders
* RS232 connect central control
* You can dial the wheel to check the current channel value.
* Press and hold the wheel and then press the Submaster button to save the Submaster
* Support Master and Slave setting to expand the channel, which can be expanded to 192 channels
* Use Page A and Page B buttons to select the channel page
* LCD display
* Power failure memory
* DMX output: XLR-D3F
* Dimension: 482 x 265 x 75 mm
* Voltage input: AC88～256V 50/60Hz
* Net weight: 2.65KG
