* Supports 8 ArtNet universes, total 4096 channels.
* Serial connection possible, which can control 32768 universes, a total of 16777216 channels
* Ethernet I/O based on high speed switch, without linking delay.
* Compatible with the following protocols: ArtNet, DMX 512 and RDM.
* It is used for extending the DMX output port of Tiger touch and MA Console.
* The 8 DMX ports can all be configured as inputs or outputs.
* DMX ports: Neutrik 3pins XLR (Option: 5 pins XLR ).
* 100% electrical isolation between all in/outputs: problems on 1 port will not influence the other ports.
* TFT display shows parameters.
* LED indicators for each input and output.
* Wide input stable electric power supply, suitable for voltage input of different countries.
* Input Voltage: AC88～256V 50/60Hz
* Dimension: 19" 1U, 482mm ×168mm × 44 mm
* Net Weight: 1.7Kg
