* DMX 512/1990 Standard
* 3 DMX inputs and 8 DMX outputs
* There are two modes of the Merger to control：HTP mode and Backup mode
* HTP: the highest value of 3 identical channels from 3 DMX-signals will have priority
* Backup: when input A DMX- signal fail, input B DMX-signal take over immediately. * When both input A & B DMX- signal fail, input C DMX-signal take over immediately
* Independent input and output signal
* Input and output ports use Inrush Protection
* Each DMX output has super driving ability. Each input and output has LED indicator
* Wide input stable electric power supply, suitable for voltage input of different countries
* Dimension: 482mm ×173mm × 46mm
* Net Weight: 1.75Kg
* Input Voltage: AC88～256V 50/60Hz
