1. Outdoor Medium power waterproof laser light with IP65 protection levels. Design with multi waterproof technique design for outdoor rainy and snowy days.
2. The housing is two independent layer structure designs which can make the laser system more stable. Top layer is the optical and electrical layer. The bottom floor is a big radiator layer with strong wind convection dissipation.
3. Not only have the basic function interface of operation, but also have the safety functions required by European and American countries.
4. Use diode solid-state laser with more stable performance and longer working life. It can work properly between -30°C to 40°C.
5. Small RGB beam diameter and low divergence to make the beam and patterns smoother and much clearer even in long distance projection.
6. Made of analog laser modulation. Users can dimmer the laser brightness linearly to make the laser light more colorful.
7. Operation interface: LCD display and touch button operation.
8. Safety Features: Single beam protection system, laser key lock and laser remote interlock switch.
9. Safety intelligent: If the scanning motor or control system fails, the scanner failure protection will shut off the laser automatically, so as to avoid the single beam coming out.
11. Applicable for outdoor and indoor stage shows, outdoor landscape lighting shows, outdoor events, etc.

Technical Specification
1.Voltage: AC100~250V/AC, 50HZ/60HZ，max consumption power: 250W
2. Laser specification:
15W:
Red laser 4.4W, wavelength 638nm
Green laser 4.8W, wavelength 520nm
Blue laser 6.5W, wavelength 450nm
Beam Diameter<4.5*6.0(H) mm, Divergence<1.1mrad
10W:
Red laser 3.3W, wavelength 638nm
Green laser 3.6W, wavelength 520nm
Blue laser 4.5W, wavelength 450nm
Beam Diameter<4.0*6.0(H) mm, Divergence<1.3mrad
3. Laser life: >10000 hours
4. Laser level: Class 4 laser
5. Waterproof Level: IP65
6. Work Environment: Outdoors and Indoors, -30 °C to 40 °C
7. Scanner: model DT40
Speed >40KPPS ILDA @8°. Max scanning angle is 60°. Signal input voltage ±5V.
Mirror 7*12mm/X and 7*12mm/Y.
The highest quality of optical scanner, high speed and high precision, high stability and long life design.
8. Working Modes: ILDA(PC control), DMX512, AUTO
Option: PANGOLIN FB4 control system
9. Interface:
3 pins XLR jack for DMX;
RJ45-ILDA interface for PC control (RJ45 cat cable is more convenient to get and wire than ILDA cable. There is no signal attenuation even after 300 meters transmission in the experiments);
RJ45 LAN Agreement for FB4 control, switch expansion interface. (The FB4 model has, the LAN in the original FB4 is automatically blocked).
10. Machine dimension: 370(L)*165(W)*210(H) mm,
11. Net Weight: 13.5Kg/10W   14.5Kg/15W
